Makita DHR242RFE + DTD158Z + DGA404Z 3-Tool Combo Set LXT 18V Cordless Brushless Rotary Hammer, Impact Driver and 100mm Angle Grinder

CONSTRUCTION COMBO

Combo Includes:

1. DHR242RFE (Rotary Hammer): Comes with 2×3.0Ah LXT batteries, rapid charger, and Makpac carry case.

2. DTD158Z (Impact Driver): Bare unit — no battery or charger included; shares battery platform with the rotary hammer.

3. DGA404Z (Angle Grinder): Bare unit — no battery or charger included; shares battery platform with the rotary hammer.

This combo set brings together three brushless LXT 18V tools for construction, renovation and installation work. The DHR242 handles rotary drilling, hammer drilling and chiselling, with a 24mm concrete capacity and 2.0J of impact energy.

The compact DTD158Z provides up to 170Nm of fastening torque for screws and compatible bolts. The DGA404Z completes the set with a 100mm grinding platform operating at 8,500rpm.

Two BL1830B 3.0Ah batteries and one DC18RC rapid charger are supplied through the DHR242RFE package and shared among all three tools.

Key Features & Benefits

• Three-Tool Coverage: Combines concrete drilling, chiselling, fastening, grinding and compatible cutting.
• 24mm Rotary Hammer: Provides three operating modes for work in concrete, wood and metal.
• 170Nm Impact Driver: Supports high-speed screwdriving and compatible bolted connections.
• 100mm Brushless Grinder: Offers cordless grinding with electronic safety functions.
• Shared LXT Platform: All three tools accept compatible Makita LXT 18V batteries.
• Two-Battery Package: Allows battery rotation or operation of two tools at once.

Technical Specifications

DHR242RFE — Cordless Rotary Hammer

• Battery Platform: LXT 18V
• Motor Type: Brushless
• Tool Holder: SDS-PLUS
• Impact Energy: 2.0J
• Concrete Capacity: 24mm
• Steel Capacity: 13mm
• Wood Capacity: 27mm
• No-Load Speed: 0–950rpm
• Blows Per Minute: 0–4,700bpm
• Operating Modes: Rotation, rotation with hammering and hammering only
• Dimensions: 328 × 85 × 213mm


DTD158Z — Cordless Impact Driver (Bare Unit)

• Battery Platform: LXT 18V
• Motor Type: Brushless
• Driving Shank: 6.35mm hex
• Maximum Fastening Torque: 170Nm
• No-Load Speed: 0–3,400rpm
• Impacts Per Minute: 0–3,600ipm
• Standard-Bolt Capacity: M5–M16
• High-Tensile-Bolt Capacity: M5–M14


DGA404Z — Cordless Angle Grinder (Bare Unit)

• Battery Platform: LXT 18V
• Motor Type: Brushless
• Wheel Diameter: 100mm
• Wheel-Bore Diameter: 16mm
• No-Load Speed: 8,500rpm
• Safety Functions: Active Feedback Sensing Technology, electric brake and anti-restart function

Package Power System

• Included Batteries: 2× BL1830B LXT 18V 3.0Ah
• Included Charger: 1× DC18RC rapid charger
• Battery Allocation: Both batteries are shared among the three tools.
• Storage: Carrying case supplied with the DHR242RFE package

Scope of Supply / What’s in the Box

DHR242RFE Rotary Hammer Package

• 1× Makita DHR242 rotary hammer
• 2× Makita BL1830B LXT 18V 3.0Ah batteries
• 1× Makita DC18RC rapid charger
• 1× Side grip
• 1× Depth gauge
• 1× Carrying case

DTD158Z Impact Driver

• 1× Makita DTD158Z brushless impact driver
• 1× Belt hook

DGA404Z Angle Grinder

• 1× Makita DGA404Z 100mm brushless angle grinder
• 1× Grinding wheel
• 1× Wheel guard
• 1× Side grip
• 1× Lock-nut wrench

Free Gift

• 1x 109566810 SDS Plus Drill Bit Set

• 3x D75518 Cutting Disc 4"

• 1x D31516 Hex Shank 1/4" Wood & Metal Drill Bit Assortment Set


Applications

• Drilling and chiselling concrete
• Drilling wood and metal with suitable accessories
• Driving screws and compatible fasteners
• Grinding suitable metal surfaces
• Compatible abrasive cut-off work
• Construction, renovation and maintenance

Why Buy This?
This set covers three frequently required construction workflows through one cordless platform. It is particularly practical for users who need concrete capability alongside everyday fastening and metalworking tools.

❇️ Prepare one LXT setup to move efficiently from concrete drilling and anchor installation to grinding and final fastening.

Frequently Asked Questions

Q: Can all three tools operate simultaneously?
The package includes two batteries, so two tools can be powered at once. A third compatible LXT battery is required to operate all three simultaneously.

Q: Can the DHR242RFE be used for chiselling?
Yes. It includes a hammering-only mode for chiselling with compatible SDS-PLUS accessories.
