Makita DHR242RFE + DHP490Z + DGA404Z 3-Tool Combo Set LXT 18V Cordless Brushless Rotary Hammer, Hammer Driver Drill and 100mm Angle Grinder

CONSTRUCTION COMBO

Combo Includes:

1. DHR242RFE (Rotary Hammer): Comes with 2×3.0Ah LXT batteries, rapid charger, and Makpac carry case.

2. DHP490Z (Hammer Driver Drill): Bare unit — no battery or charger included; shares battery platform with the rotary hammer.

3. DGA404Z (Angle Grinder): Bare unit — no battery or charger included; shares battery platform with the rotary hammer.

This combo set provides complementary drilling and metalworking tools on the Makita LXT 18V platform. The DHR242RFE delivers 2.0J of impact energy and three operating modes for concrete drilling and chiselling.

The compact DHP490Z adds hammer drilling, conventional drilling and screwdriving with a 13mm keyless chuck and up to 65Nm maximum torque. The DGA404Z provides brushless 100mm grinding capability with an electric brake and electronic safety functions.

The DHR242RFE package supplies two BL1830B 3.0Ah batteries and one DC18RC rapid charger for shared use across the set.

Key Features & Benefits

• Complementary Drilling Tools: Combines dedicated SDS-PLUS concrete performance with a versatile keyless-chuck drill.
• 24mm Rotary Hammer: Handles hammer drilling, rotary drilling and chiselling.
• 65Nm Hammer Driver Drill: Supports general drilling, masonry drilling and controlled screwdriving.
• 100mm Angle Grinder: Provides cordless grinding and compatible cut-off capability.
• Brushless Motors: Used across all three tools for efficient cordless operation.
• Shared LXT Batteries: Keeps the complete set on one established 18V platform.

Technical Specifications

DHR242RFE — Cordless Rotary Hammer

• Battery Platform: LXT 18V
• Motor Type: Brushless
• Tool Holder: SDS-PLUS
• Impact Energy: 2.0J
• Concrete Capacity: 24mm
• Steel Capacity: 13mm
• Wood Capacity: 27mm
• No-Load Speed: 0–950rpm
• Blows Per Minute: 0–4,700bpm
• Operating Modes: Rotation, rotation with hammering and hammering only
• Dimensions: 328 × 85 × 213mm


DHP490Z — Cordless Hammer Driver Drill (Bare Unit)

• Battery Platform: LXT 18V
• Motor Type: Brushless
• Chuck Capacity: 1.5–13mm
• Maximum Torque: 65Nm
• Fastening Torque: 50Nm hard / 27Nm soft
• No-Load Speed: 0–500rpm / 0–1,900rpm
• Impacts Per Minute: 0–7,500ipm / 0–28,500ipm
• Steel Capacity: 13mm
• Wood Capacity: 38mm
• Masonry Capacity: 13mm


DGA404Z — Cordless Angle Grinder (Bare Unit)

• Battery Platform: LXT 18V
• Motor Type: Brushless
• Wheel Diameter: 100mm
• Wheel-Bore Diameter: 16mm
• No-Load Speed: 8,500rpm
• Safety Functions: Active Feedback Sensing Technology, electric brake and anti-restart function

Package Power System

• Included Batteries: 2× BL1830B LXT 18V 3.0Ah
• Included Charger: 1× DC18RC rapid charger
• Battery Allocation: Both batteries are shared among the three tools.
• Storage: Carrying case supplied with the DHR242RFE package

Scope of Supply / What’s in the Box

DHR242RFE Rotary Hammer Package

• 1× Makita DHR242 rotary hammer
• 2× Makita BL1830B LXT 18V 3.0Ah batteries
• 1× Makita DC18RC rapid charger
• 1× Side grip
• 1× Depth gauge
• 1× Carrying case

DHP490Z Hammer Driver Drill

• 1× Makita DHP490Z brushless hammer driver drill
• 1× Driver Bit
• 1× Belt hook

DGA404Z Angle Grinder

• 1× Makita DGA404Z 100mm brushless angle grinder
• 1× Grinding wheel
• 1× Wheel guard
• 1× Side grip
• 1× Lock-nut wrench

Free Gift

• 1x 109566810 SDS Plus Drill Bit Set

• 3x D75518 Cutting Disc 4"

• 1x D31516 Hex Shank 1/4" Wood & Metal Drill Bit Assortment Set


Applications

• Drilling and chiselling concrete
• Hammer drilling masonry
• Drilling wood and metal
• Driving screws and suitable fasteners
• Grinding and compatible abrasive cutting
• Construction and installation work

Why Buy This?
The combination separates demanding concrete work from everyday drilling and fastening while retaining one shared battery platform. The grinder further extends the set into metal preparation and compatible cutting applications.

❇️ Build a versatile LXT work setup for structural drilling, general installation and metal preparation without changing battery systems.

Frequently Asked Questions

Q: Why does this set include two different drilling tools?
The DHR242 is designed for more demanding SDS-PLUS concrete drilling and chiselling. The DHP490 offers a conventional keyless chuck for general drilling, hammer drilling and screwdriving.

Q: How many batteries are supplied?
Two BL1830B 3.0Ah batteries are included and shared among all three tools.
