The Grundfos SCALA2 3-45 is a compact all-in-one booster pump with integrated speed control. It adjusts its speed to demand to help deliver comfortable water pressure to showers, taps and everyday household water use. It comes with a 0.45 kW motor, a built-in pressure tank and a 1.5 m power cable with plug for convenient electrical connection.
Key Features & Benefits
- Improved Household Water Pressure: Helps boost water pressure for showers, taps and household water needs, making everyday use more comfortable.
- Integrated Speed Control: The pump adjusts its speed to match water demand, helping keep pressure steady as taps open and close.
- All-in-One Compact Design: Pump, motor, tank, sensor, drive and non-return valve are combined in one compact unit.
- Self-Priming (Where Supported): Grundfos describes the SCALA2 as self-priming, able to draw water from a depth of up to 8 m once the pump is filled with water. Self-priming does not apply to versions fitted with a locking pin, so confirm the pump configuration with CT Hardware before installing with suction lift.
- Dry-Running Protection: Integrated dry-running protection helps protect the pump if water runs short.
- Quiet Operation: A water-cooled permanent magnet motor keeps the noise level at 47 dB(A) in typical use.
- User-Friendly Control Panel: The control panel on the pump lets you set the pressure to suit your household.
- Indoor or Outdoor Installation: The IPX4D enclosure rating allows indoor or outdoor installation, following the Grundfos installation conditions.
- Composite Pump Housing and Impeller: The pump housing and impeller are made of composite material.
- Easy Installation: Supplied with 1-inch male inlet and outlet connections and a 1.5 m power cable with plug for straightforward connection during installation.
What Is the SCALA2?
SCALA2 is the Grundfos all-in-one home booster with integrated speed control. The pump, motor, tank, sensor, drive and non-return valve are combined in one compact unit, and the pressure is set on the pump's own control panel.
It suits homeowners who want a compact, quiet, ready-to-install booster for a home with up to 3 floors and 8 taps.
Technical Specifications
- Model: Grundfos SCALA2 3-45
- Pump type: All-in-one booster with integrated speed control
- Grundfos product code: 93013322
- Motor power (P2): 0.45 kW
- Power input (P1): 550 W
- Power supply: 200–240 V, 50/60 Hz, single-phase
- Power cable: 1.5 m with plug
- Maximum flow: About 77 L/min (approx. 4.6 m³/h)
- Maximum head: 45 m
- Maximum system pressure: 10 bar
- Maximum inlet pressure: 6 bar
- Liquid temperature: 0 to +45 °C
- Ambient temperature: 0 to +55 °C
- Maximum suction lift: 8 m (versions without a locking pin)
- Inlet connection: R 1 (1-inch male)
- Outlet connection: R 1 (1-inch male)
- Pump housing: Composite
- Impeller: Composite
- Enclosure rating: IPX4D; suitable for outdoor installation
- Sound pressure level: 47 dB(A) in typical use
- Length: 403 mm
- Width: 193 mm
- Height: 302 mm
- Weight: 10 kg
- Pumped liquid: Clean water
Where It Works Best
The Grundfos SCALA2 3-45 is designed for residential buildings with up to 3 floors and 8 taps. Whether you're dealing with weak shower pressure or slow-running taps, it helps make everyday water use more comfortable.
- Residential Homes: Designed for residential buildings with up to 3 floors and 8 taps, as stated by Grundfos.
- Boosting from Water Tanks: Increases water pressure from roof tanks, break tanks and ground tanks, including rainwater tanks.
- Boosting from Wells: Pumps water from a depth of up to 8 m on versions without a locking pin, subject to the conditions in the Grundfos installation instructions.
How Many Bathrooms Can It Support?
- Grundfos sizing guide: Designed for residential buildings with up to 3 floors and 8 taps.
- CT Hardware estimate: Typically suited to about 2–3 bathrooms. This is an indicative estimate by CT Hardware, not a Grundfos figure.
The recommended bathroom count depends on your home's water supply, plumbing layout, shower type and the number of outlets used simultaneously.
For homes with rain showers or higher water demand, check the appropriate pump size before purchasing.
Water Supply & Installation Requirements
Grundfos describes the SCALA2 3-45 as self-priming, with a maximum suction lift of 8 m. Self-priming does not apply to versions fitted with a locking pin, so the pump configuration must be confirmed before it is installed with suction lift. The maximum inlet pressure is 6 bar.
Before First Use: The pump must be filled with water before starting. Follow the Grundfos SCALA2 installation and operating instructions for the correct priming and startup procedure.
The pump can be installed indoors or outdoors, but it must be protected from frost. Install it on a firm, level surface in a well-ventilated location, protected from rain, direct sunlight and dust, within the ambient temperature range of 0 to +55 °C. Check that the voltage and frequency on the nameplate match your supply. Plumbing and electrical connections must follow Grundfos installation instructions and applicable local requirements, and the Grundfos installation instructions set out the suction and water supply conditions required before installation.
Need help choosing the right pump? Contact CT Hardware with your water source, number of bathrooms and shower types. Our team can assist with product selection, although installation should be handled by a qualified installer.
Compare & Choose
- Want Bluetooth set-up with the Grundfos GO app? The Grundfos SCALA1 3-45 adds built-in Bluetooth, with a 0.58 kW motor.
- Explore other Grundfos SCALA models: Browse our Grundfos SCALA Pumps collection to compare the SCALA range.
- Prefer a different type of booster pump? Explore our Grundfos Booster Pumps collection for other booster options.
- Not sure which pump suits your home? Our Grundfos Booster Pump Buying Guide helps you compare models based on your bathroom requirements and water supply.
Warranty & Certification
- 2-Year Manufacturer Warranty: Backed by a Grundfos 2-year warranty, subject to applicable terms and conditions. View our Grundfos Warranty Guidelines for coverage and registration details.
- Grundfos DBS Professional Dealer: CT Hardware Sdn Bhd is listed in Grundfos Malaysia's Domestic Building Services (DBS) Professional Dealer directory.
