Makita UH201DWAX + HP332DZ + HR166DZ 3-Tool Combo Set CXT 12Vmax Cordless 200mm Hedge Trimmer, Brushless Hammer Driver Drill and Rotary Hammer

12V CORDLESS COMBO

Combo Includes:

1. UH201DWAX (Hedge Trimmer): Comes with 1×2.0Ah CXT battery and charger.

2. HP332DZ (Hammer Driver Drill): Bare unit — no battery or charger included; shares battery platform with the hedge trimmer.
3. HR166DZ (Rotary Hammer): Bare unit — no battery or charger included; shares battery platform with the hedge trimmer.

This combo set combines compact garden maintenance with drilling and installation capability on the CXT 12Vmax platform. The UH201DWAX uses a 200mm hedge-trimmer blade operating at 2,500 strokes per minute for trimming suitable small hedges, shrubs and decorative plants.

The brushless HP332DZ covers drilling wood and metal, hammer drilling suitable masonry and controlled screwdriving. Its two-speed gearbox delivers up to 35Nm hard fastening torque through a compact 10mm keyless chuck.

For dedicated concrete drilling, the brushless HR166DZ uses SDS-PLUS bits and delivers 1.1J impact energy. Two operating modes allow rotation-only drilling or rotation with hammering.

The UH201DWAX package supplies one BL1021B 2.0Ah battery and one DC10WD charger for shared use among all three tools.

Key Features & Benefits

• Three-Task Combination: Covers hedge maintenance, general drilling and dedicated concrete drilling.
• Compact Hedge Trimmer: Uses a 200mm blade with dual cutting action for detailed garden work.
• Brushless Hammer Driver Drill: Provides drilling, hammer drilling and controlled fastening in a compact format.
• SDS-PLUS Rotary Hammer: Delivers 1.1J impact energy for suitable concrete and masonry applications.
• Shared CXT Platform: All three tools use compatible Makita CXT 12Vmax slide batteries.
• Ready Power Package: Includes one 2.0Ah battery and a compatible charger.

Technical Specifications

UH201DWAX — Cordless Hedge Trimmer

• Battery Platform: CXT 12Vmax
• Blade Length: 200mm
• Tooth Spacing: 26mm
• Strokes Per Minute: 2,500spm
• Blade Action: Dual cutting action
• Blade Change: Tool-less removal system
• Dimensions: 504 × 120 × 131mm
• Weight with Battery: Approximately 1.3–1.5kg


HP332DZ — Cordless Hammer Driver Drill

• Battery Platform: CXT 12Vmax
• Motor Type: Brushless
• Chuck Capacity: 0.8–10mm
• Fastening Torque: 35Nm hard / 21Nm soft
• Torque Settings: 20
• No-Load Speed: 0–450rpm / 0–1,500rpm
• Impacts Per Minute: 0–6,750ipm / 0–22,500ipm
• Steel Capacity: 10mm
• Wood Capacity: 28mm
• Masonry Capacity: 8mm
• Overall Length: 168mm


HR166DZ — Cordless Rotary Hammer

• Battery Platform: CXT 12Vmax
• Motor Type: Brushless
• Bit Holder: SDS-PLUS
• Impact Energy: 1.1J
• Concrete Capacity: 16mm
• Steel Capacity: 10mm
• Wood Capacity: 13mm
• No-Load Speed: 0–680rpm
• Blows Per Minute: 0–4,800bpm
• Operating Modes: Rotation only and rotation with hammering
• Dimensions: 250 × 74 × 187mm
• Weight with Battery: Approximately 1.8–2.4kg

Package Power System

• Included Battery: 1× BL1021B CXT 12Vmax 2.0Ah
• Included Charger: 1× DC10WD charger
• Battery Allocation: The battery is shared among all three tools.
• Simultaneous Operation: Additional compatible CXT batteries are required to operate more than one tool at the same time.


Scope of Supply / What’s in the Box

UH201DWAX Hedge Trimmer Package

• 1× Makita UH201D 200mm hedge trimmer
• 1× Makita BL1021B CXT 12Vmax 2.0Ah battery
• 1× Makita DC10WD charger
• 1× Hedge-trimmer blade
• 1× Blade cover
• 1× Chip receiver

HP332DZ Hammer Driver Drill

• 1× Makita HP332DZ brushless hammer driver drill
• 1× Phillips driver bit
• 1× Belt clip

HR166DZ Rotary Hammer

• 1× Makita HR166DZ brushless SDS-PLUS rotary hammer
• 1× Side grip
• 1× Depth gauge

Free Gift

• 1× 109566810 SDS Plus Drill Bit Set

• 1× D31516 Hex Shank 1/4" Wood & Metal Drill Bit Assortment Set

Applications

• Trimming suitable small hedges and shrubs
• Drilling wood and metal
• Hammer drilling suitable masonry
• Driving screws and compatible fasteners
• SDS-PLUS drilling in concrete
• Garden, installation and property-maintenance work

Why Buy This?
This set combines compact outdoor maintenance with two distinct drilling systems. The HP332 handles everyday drilling and fastening, while the HR166 provides an SDS-PLUS platform for more focused concrete work.

❇️ Equip your CXT system for garden upkeep, everyday installation and concrete drilling with one compact three-tool package.

Frequently Asked Questions

Q: Why does this set include two drilling tools?
The HP332DZ uses a conventional keyless chuck for wood, metal, masonry and screwdriving. The HR166DZ uses SDS-PLUS bits and is designed for more focused concrete drilling.

Q: Can all three tools operate at the same time?
No. One battery is included and must be transferred between the tools. Additional compatible CXT batteries are required for simultaneous operation.
